A Technical appendix
66 Festo – GDCP-CMMP-M0-HW-EN – 1511c – English
Operating and environmental conditions
CMMP-AS- C2-3A-M0 C5-3A-M0 C5-11A-P3-M0 C10-11A-P3-M0
Permissible setup altitude above sea level
with rated
output
[m] 1000
with power re
duction
1)
[m] 1000 … 2000 (max.)
Air humidity [%] 0 … 90 (non-condensing)
Protection class IP20 (with plugged-in plug connectors at X6 and X9)
IP10 (without plugged-in plug connectors at X6 and X9)
Degree of
contamination
2
Operating tem
perature
[°C] 0 … +40
Operating
temperature with
power reduction
of 2.5 % per
Kelvin
[°C] +40 … +50
Switch-off
temperature,
heat sink power
section
[°C] 100 80 80 80
1) Above 1000 m above sea level Performance reduction of 1% per 100 m
Tab. A.3 Technical data: Operating and environmental conditions
Electrical data logic supply
CMMP-AS- C2-3A-M0 C5-3A-M0 C5-11A-P3-M0 C10-11A-P3-M0
Nominal voltage [V DC] 24 ±20%
Nominal current
1)
[A] 0.55 0.65 1
Maximum current
for holding brake
[A] 1 2
With higher power requirement of the holding brake è Fig. 4.5 page 38
1) plus current consumption from an existing holding brake and I/Os
Tab. A.4 Technical data: Logic supply
Note
With a warm motor and a supply voltage that is too low (outside of tolerance), the mo
tor's brakes cannot open 100%, which can lead to premature wearing of the brake.
