Festo CMMP-AS-C5-11A-P3-M0 User Manual

A Technical appendix
70 Festo – GDCP-CMMP-M0-HW-EN – 1511c – English
CMMP-AS-C2-3A-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 2.5 2.2 2.5 2.5
Maximum output current for maximum time (effective value)
Max. output current [A] 5 4.4 5 5
Max. time [s] 5 5 5 5
Max. output current [A] 7.5 6.6 7.5 7.5
Max. time [s] 1.3 1.3 1.3 1.3
Max. output current [A] 10 8.8 10 10
Max. time [s] 0.5 0.5 0.5 0.5
1) Option with FCT able to be parametrised
Tab. A.10 Output data CMMP-AS-C2-3A-M0
CMMP-AS-C5-3A-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 5 4.4 5 5
Maximum output current for maximum time (effective value)
Max. output current [A] 10 8.8 10 10
Max. time [s] 5 5 5 5
Max. output current [A] 15 13.2 15 15
Max. time [s] 1.3 1.3 1.3 1.3
Max. output current, effective [A] 20 17.6 20 20
Max. time [s] 0.5 0.5 0.5 0.5
1) Option with FCT able to be parametrised
Tab. A.11 Output data CMMP-AS-C5-3A-M0

Festo CMMP-AS-C5-11A-P3-M0 Specifications

General

Brand	Festo
Model	CMMP-AS-C5-11A-P3-M0
Category	Controller
Language	English
