Festo CMMP-AS-C5-11A-P3-M0 User Manual

A Technical appendix
Festo – GDCP-CMMP-M0-HW-EN – 1511c – English 71
CMMP-AS-C5-11A-P3-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 5 2.5 5 5
Maximum output current for maximum time (effective value)
Max. output current [A] 10 5 10 10
Max. time [s] 5 5 5 5
Max. output current [A] 15 7.5 15 15
Max. time [s] 0.8 1.2 0.8 0.8
Max. output current [A] 20 10 20 20
Max. time [s] 0.1 0.15 0.1 0.1
1) Option with FCT able to be parametrised
Tab. A.12 Output data CMMP-AS-C5-11A-P3-M0 with electrical rotation frequency  5 Hz
CMMP-AS-C5-11A-P3-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 5 2.5 5 5
Maximum output current for maximum time (effective value)
Max. output current [A] 10 5 10 10
Max. time [s] 5 5 5 5
Max. output current [A] 15 7.5 15 15
Max. time [s] 2 2 2 2
Max. output current [A] 20 10 20 20
Max. time [s] 0.5 0.5 0.5 0.5
1) Option with FCT able to be parametrised
Tab. A.13 Output data CMMP-AS-C5-11A-P3-M0 with electrical rotation frequency  20 Hz
