A Technical appendix
72 Festo – GDCP-CMMP-M0-HW-EN – 1511c – English
CMMP-AS-C10-11A-P3-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 8 3.45 10 8
Maximum output current for maximum time (effective value)
Max. output current [A] 16 6.9 20 16
Max. time [s] 5 5 5 5
Max. output current [A] 24 10.35 30 24
Max. time [s] 0.1 0.2 0.1 0.1
Max. output current [A] 32 13.8 40 32
Max. time [s] 0.07 0.15 0.07 0.07
1) Option with FCT able to be parametrised
Tab. A.14 Output data CMMP-AS-C10-11A-P3-M0 with electrical rotation frequency  5 Hz
CMMP-AS-C10-11A-P3-M0
Cycle time current regulator
1)
[µs] 62.5 125
Half output stage frequency
1)
active inactive active inactive
Output stage frequency [kHz] 8 16 4 8
Rated output current, effective [A] 8 3.45 10 8
Maximum output current for maximum time (effective value)
Max. output current [A] 16 6.9 20 16
Max. time [s] 5 5 5 5
Max. output current [A] 24 10.35 30 24
Max. time [s] 2 2 2 2
Max. output current [A] 32 13.8 40 32
Max. time [s] 0.5 0.5 0.5 0.5
1) Option with FCT able to be parametrised
Tab. A.15 Output data CMMP-AS-C10-11A-P3-M0 with electrical rotation frequency  20 Hz
