Festo CP Series User Manual

The CP terminals are available in the following sizes:Grid sizes of
the CP terminals
Designation Valve plate Valve
CPV10 10 mm Micro valves
CPV14 14 mm Mini valves
CPV18 18 mm Midi valves
Mixed operation with both grid sizes on one CP termi-
nal is not permitted.
You can divide the CP valve terminal into two pressure
zones with the aid of the isolating plate. The isolating
plate is available in two variants:
Isolating plate
– Isolating plate with blocked compressed air channels
(1 and 11)
– Only CPV14: isolating plate with blocked exhaust
channels (3/5) and blocked compressed air channels
(1 and 11)
The CP valve terminal with CP connection can be fitted
with relay plates. Each relay plate contains two relays
for controlling two electrically-isolated outputs.
Relay plate
1. System overview
1-6 CPV... 9802
