On the CP valve terminal with single electrical connec-
tions you will find the following electrical connections
and display elements:
1
2
3
4
5
6
7
Label fields (per cable socket)
Type plate
Connecting lugs for pilot solenoid valve 14
Earth/ground connection (per end plate)
Connecting lugs for pilot solenoid coil 12
Yellow LEDs, signal status displays of pilot solenoids
(per cable socket)
Ready-made cable with socket for individual connection
(per pilot solenoid), can be turned 180°.
Fig. 1/5: Electrical connections and display elements
of the CP valve terminal with IC connection
1
2
5
7
6
3
4
1. System overview
1-12 CPV... 9802
