2. Commissioning
2-53
Festo P.BE-CPX-PNIO-EN en 1407c English
2. Mark the symbol of the CPX terminal on the PROFINET- IO
system (see 1 Fig. 2/14). Th e configuration table now
shows the configuration of the CPX terminal.
3. Double click on line 0 of the configuration table 2.The
“Properties CPX” dialogue window is displayed.
4. Choose the “Parameter” tab 3.
The list with the parameters and the currently active val-
ues will be shown.
5. Click on the parameter value (“Value”) which you wish to
modify.
A list field with the possible values is opened 4.
6. Change the parameter by clicking on the desired value
(“Value”).
7. Confirm the ch an ge to close.
Note
System parameters monitoring KZS/KSA/KZV, U
OUT/VAL
The short-circuit /overload and undervoltage diagnostic
messages for the complete CPX terminal can be sup-
pressed usin g the monitoring system parameter (function
no. 4401).
The settings made separately for each module with the
CPX Module parameter monitoring are not affected by the
setting of the system parameters monitoring.
Further information about parameterisation can be found
in the CPX system description (P.BE-CPX-SYS...) in ap-
pendix B.
