1. Installation
1-27
Festo P.BE-CPX-PNIO-EN en 1407c English
1.7 Ensuring the protection class
•
Use connection technology with the required degree of
protection ( www.festo.com/catalogue, examples
in Tab. 1/10).
•
Use co ver caps to seal unused connecti o ns.
Connection
Connection technology Cover cap
CPX-FB33:
Network connection (M12)
Plug connector NECU-M-S-D12G4-C2-ET ISK-M12
2)
CPX-M-FB34:
Network connection (RJ45)
Plug connector FBS-RJ45-PP-GS
CPX-M-AK-C
CPX-M-FB35:
Network connection (S CRJ)
Plug FB S-SCRJ-PP-GS
Service interface Connecting cable KV-M12-M12-…
1)
ISK-M12
2)
1) Connec ting c able for the operator unit (CPX-MMI)
2) Included in scope of delivery
Tab. 1/10: Connectio n technol ogy and cover caps for degree of protection IP65/IP67
(examples)
