A. Technical appendix
A-5
Festo P.BE-CPX-PNIO-EN en 1407c English
A.3 Technical data, b us node CPX-M-FB35
General characteristics CPX-M-FB35
General technical data See CPX system description P.BE-CPX-SYS-...
Degree of protection through housing
in accordance with I EC/DI N EN 60529,
completely mounted, plug connector inserted or
provided with cover cap
I P65/IP67
Protection against electric shock
Protection against direct and indirect contact in
accordance with IEC/DIN EN 60204-1
by means of PELV circuit
(Protected Extra Low Voltage)
Module code (CPX-specific)
– Remote I/O
– Remote controller
217
166
Module identifier ( in the PLC, CPX-FMT or
CPX-MMI)
– Remote I/O
– Remote controller
FB35-RIO ProfiNet FOC remote I/O
FB35-RC ProfiNet FOC bus node
Power supply CPX-M-FB35
Operating voltage/load voltage See CPX system description P.BE-CPX-SYS-...
Intrinsic current consumption of bus node at
24 V DC
from operating voltage supply for
electronics/sensors (U
EL/SEN
)
typ. 150 mA
(internal electronics)
Separation
PROFIN ET interfaces to U
EL/SEN
Galvanically separated through fibre-optic cable
Mains buffering time 10 ms
