A. Technical appendix
A-6
Festo P.BE-CPX-PNIO-E N en 1407c English
A.4 Network-specific technical data
bus node CPX-FB33, CPX-M-FB34 and CPX-M-FB35
Network-specific characteristics
Fieldbus protocol PROFINET IO RT/IRT (PNIO RT/IRT):
– based on Industrial Ethernet
– based on the Ethernet protocol (IEEE 802.3)
– real-time-capable
– supports LLDP
Supported protocol characteristics and protocol
functions (selection)
– LLDP
– Access via SNM P
–FastStart-up(FSU)
– PROFIenergy
–PROFIsafe
–Shareddevice
– Media redundancy (MRP)
Supported CPX characteristics and functions
(selection)
– CPX-terminal configuration through CPX-FMT
– Export/import of the CPX-terminal
configuration through CPX-FMT and control
system (“export function”)
– CPX t erminal diagnostics via the fieldbus and
control system
– Webserver function:
representation of the PROF IN ET topology, CPX
terminal configuration with diagnostic
information, PROFINET-I&M data, Ethern et
statistics
Specification Selection of directives, standards an d norms
regarding PROFINET:
– PROFINET installation guidelines
(“PROFINET Installation Guide”,
“Installation Guideline PROFINET Part 2…”)
– I EC 61158
– I EC 61784
– I EC 61918
For additional information:
www.profinet.com
www.profibus.com/download/
