Ø
Enable: a tick [
3] indicates if the detector is enable.
Ø
LED Blinking: a tick [
3] indicates if the LED de
-
tector is enable or disable.
Ø
Label: this is for the editable device-label. The
system will use the label as the device identifier
.
Ø
Address: in this field you can modify the address of
the detector;
Options section:
Ø
assigned zones: each fire detector, Input module and
Manual call Point can be associated with 1 of the avala
-
ible software zones (64 for FC510, 128 for FC520 con
-
trol panel). If a device goes into ALARM status, all the
zones it is connected to (assigned zones) will also go
into ALARM status.
Ø
Base In this section it is possible to select the base
for the detector (click on available bases).
Ø
Processing section:
Processing: this determines the actions the control
panel will perform when the device threshold is exce
-
eded.
Drift Compensation: Drift compensation effects analo
-
gue smoke sensors only. It will supply a precise anal
-
ysis about dust accumulation, and therefore, the alarm
threshold will be modified accordingly.
Use zone setting: the detector uses the parameters
of the assigned zone; if this options is disabled, the pro
-
cessing type will be selected.
Prealarm - the control panel will activate the ALARM
delay
;
Warning - the control panel will activate a WARNING
signal.
Operating mode Heat detector:
Day mode-Night mode for Temperature detector (see
table 6).
Operating mode Smoke detector: Day mode-Night
mode for Smoke and Heath detectors:
Ø
Default: for smoke detectors only (813P) and for
Smoke and Heath detectors only (801PH)
Ø
Enhanched: (for Smoke and Heath detectors only)
Ø
Sensitivity: Sensitivit can set:
Low, Medium and High.
+
Click-on yellow bar to open or close the relative
section of parameters programming
+
If a detector linked to an Output or Input-Output Mo
-
dule, will be disabled (remove a tick [3] in the proper
section), a window will shown to ask confirmation.
Click on Detail to see further data (Figure 27).
+
Only for the sirens of the series FC410LPA / S and
their base FC430LPA / S the window "Advanced"
opens in which you program, tone, volume and fre
-
quency of the flashing
n
Input modules programming
Click-on an entered Input Modules, the relative pro
-
gramming window will shown as per the following de
-
scription.
Input module section: as per the same Detectors
section;
Assigned zones: as per the same Detectors section;
Operating mode section: select the operating mode
style: B, C.
There are 2 operating mode style: B, C;
Ø
Bstyle: two wire connection mode: the short-circuit
condition as an Alarm condition.
Ø
C style: two wire connection mode: the short-circuit
condition as a Fault condition.
+
As different styles are selected, the electrical ope
-
rating diagram changes
n
Output modules programming
Click-on an entered Output Modules, the relative pro
-
gramming window will shown as per the following de
-
scription.
Output module section: as per the same Detectors sec
-
tion;
Assigned zones: each Output module can be associa
-
ted with up to 4 of the 64 avalaible software zones for
FC510 control panel, (128 for FC520). An Output mo-
dule will activated when the zones where is enabled will
go into ALARM status.
Base In this section it is possible to select the base for
the Output module, click on available bases (for
FC430SAM and FC430SAB only).
Beacon It is possible activate the blinking or glowing (ON)
Assigned points: each Output module can be associa-
ted with 3 Input Points. If any one of its Input Points
goes into ALARM status, the Output module will activa
-
te. For each Point it is necessary to indicate:
Ø
the loop the device is connected to (1 or 2);
Ø
the device address.
Options section: this option will allow you to select the
conditions that will activate the output module:
Ø
Zone warning, Zone fault, Zone Prealarm, Zone Alarm,
Zone Double Knock;
Ø
Point warning, Point fault, Point Prealarm, Point
Alarm,
Ø
Panel warning, Panel fault, Panel prealarm, Panel
alarm,
Ø
Network warning, Network fault, Network prealarm,
Network alarm,
moreover it is possible to program the Output Module
as: Silenceable, Pass trough and Walk test.
Linked Delay see the same option in the paragraph
"Output Programming".
n
Multiple Input-Output Module - Programming
Parameters (FC410MIO)
Click-on an entered Multiple Input/Output Module
FC410MIO (3 Input Modules and 4 Outputs Modules,
PC PROGRAMMING 33
