4B-I - Isolator Base
The FC400/FC460 Series Detectors, as supplied, use a
common 4B-I Isolator Base assembly.
The base may be fixed directly to:
Ø
British (fixing centres 50mm) or European (fixing
centres 70mm) conduit box;
Ø
Euro Mounting Box AB-EM;
Ø
suspended ceiling, via the CTA adapter;
Ø
Directly to the ceiling.
FC490ST - Loop Service Tool
The FC490ST Loop Service Tool is used to program
the loop address into FC addressable devices. The
FC490ST displays information and performs tests on
devices. It has a 32 character backlit LCD alphanume
-
ric display, arranged in 2 rows of 16 characters and
four ‘softkeys’, F1, F2, F3 and F4. Power for the
FC490ST is derived from 4 AA size nickel metal hydri
-
de rechargeable batteries. It may be run from an unre
-
gulated +12V dc input ie, car cigarette lighter
connection or 110/230V ac mains adaptor, both of
which will recharge the batteries as well.
FC410BDM - Beam Detector Module
The FC410BDM Beam Detector Interface Module is de-
signed to interface FIRERAY 50 Beam Detectors to the
FC Digital Addressable Loop (it must not be used with
other types of beam detector). The FC410BDM moni-
tors the Fire and Fault contacts and also monitors for
open and short circuits on the connections between the
interface and the beam detector. For remote siting of
the FIRERAY 50 an optional BTM800 Terminal Module
can be used with 4 core cable.
The FIRERAY 50 transmitter and receiver units are mo-
unted in the same housing.
The FC410BDM Loop Powered Beam Detector Interfa
-
ce Module is contained on a double sided printed circuit
board (PCB) which is fitted into a custom built fascia
plate with a protective cover being fitted over the PCB,
leaving only the connection terminals exposed. The fa
-
scia plate is then fitted onto a standard dual-gang back
box with BESA fittings.
FC410CIM - Contact Input Module
The FC410CIM FC Addressable Contact Input Module
is designed to monitor fire contacts such as extingui
-
shing system control, ventilation control, fire door con
-
trol etc. The FC410CIM can be configured as:
Ø
Two spur circuits (Class B) monitoring multiple nor
-
mally open contacts, with short circuit giving a fault
output.
Ø
Two spur circuits (Class B) monitoring single nor
-
mally closed contacts, with short circuit giving a fault
output.
Ø
Two spur circuits (Class B) monitoring multiple nor
-
mally open contacts, with short circuit giving an alarm.
FC410DIM - Detector Input Module
The Addressable FC410DIM provides the ability to con
-
nect and Interface one or two zones of 24V dc 2-wire
conventional detectors (non-addressable) to the Fire
Alarm Controller.
The FC410DIM monitors the status of detectors and wi
-
ring to detectors and signals detector and wiring status
back to the Controller.
FC410RIM - Relay Interface Module
The FC410RIM Relay Interface Module provides one
volt-free relay changeover contact on a latching relay. The
relay is controlled by a command sent from the FC fire
controller via the addressable loop. The relay state (acti
-
vated, deactivated or stuck) is returned to the controller.
FC400CH - Addressable Carbon Monoxide
+ Heat Detector
The FC400CH carbon monoxide plus heat detector forms
part of the FC400 Series Addressable Fire detectors.
The detector is intended to plug into the following:
Ø
5B 5” Universal Base.
Ø
FC450IB 5” Isolator Base.
Ø
FC430SB Low Power Sounder Base.
The detector is designed to transmit, to a remote Fire
Class controller, digital signals which represent status of
the carbon monoxide and heat elements of the detector.
Software within the controller is used to interpret the re-
turned carbon monoxide and heat values to raise alarm
or other appropriate response according to the type of
detector configured in Fire Class 500 Console.
801RIL - Remote LED Indicator
The 801RIL Remote Indicator is used where a detector
LED is not visible ie, when the detector is mounted in a
roof void, lift shaft etc.The 801RIL is mounted to a single
gang electrical box and is supplied with 2 x M3.5 screws.
801HL - Remote LED Indicator
The 801HL Remote Indicator is used where a detector
LED is not visible ie, when the detector is mounted in a
roof void, lift shaft etc.
The 801HL provides a larger indicator for use in place of
the 801RIL when longer distances are involved or in
VdS influenced markets.
The 801HL can be mounted to any suitable flat surface
and has fixing centres at 60 and 80mm.
HVR800-High Voltage Relay
The HVR800 High Voltage Relay Interface is a non-ad
-
dressable multi-voltage relay module (operating from
24V dc, 24V ac, 120V ac and 240V ac).
The encapsulated HVR800 provides a 10 amp volt-free
contact that can be used to extend the contact ratings of
FC410RIM Addressable Relay Module applications.
A maximum of four HVR800s can be individually driven
56 Addressable Fire Control Panels FC500
