QUICK GUIDE
This quick guide is for installers with knowledge of the
control panels, and fire control panels in general. This
chapter holds all the necessary installation details.
Technical features
Some of the technical features, regarding the terminals
on the Main, are described in the following paragraph.
The following table shows the technical features of the
Repeater FC500REP.
REPEATER FC500REP
Main voltage 27,6 V
Maximum current 180 mA
Temperature range -5 ÷ +40°
Dimensions (W*H*D) 390x215x50 mm
Weight 2,05 Kg
Description of the terminals
The terminals of the Main board and Switching power
supply, are described briefly in the a Table 8: the
standby (normal) status is the first, followed by the
alarm status. Moreover, the Voltage present during the
different operating conditions is indicated for each ter-
minal, as well as the maximum current (in amps) that
can circulate.
In the following table the current values of every fun-
ctions of control panel.
Avalaible Current 5,5A 5,5A
ttery capacity 17Ah 38Ah
Battery charge 1A 2A
NACs Outputs 2A 1A
Auxiliary Outputs
(24AUX, 24RES)
0,5A 0,5A
LOOPs (2) 0,8A 0,8A
12V Output 0,15A 0,15A
Conventional Zone 0,06A 0,06A
1) For the power supply of the external devices. (see
table 8)
2) Connect a 3900 ohm resistor between the [+] and [-]
terminals of the NAC1, NAC2 and NAC3 Outputs, if not
used (see table 8).
QUICK GUIDE 59
Control Panel FC510-FC520
Main voltage
110/230 V~
60/50 Hz -15/+10%
Aux. Outputs
Nominal Voltage
27,6 V
Aux. Outputs Min.
and Max. Voltage
19,0 ÷ 27,6 V
Minimum output
voltage
19,0V±5%
Max. current draw
1,6 A (230V)
2,7 A (110V)
Power 35 W
Maximum avalaible
current (1)
4,2 A with 17Ah batteries
3,2 A with 38Ah batteries
Control Panel max.
current draw at 27.6V
0,3 A
Ripple 1%
Suitable batteries:
make
model
2 * 12 V/17 Ah
YUASA
NP 17-12 FR
or equivalent with case
flame class UL94-V2 or
higher
Maximum internal
resistance of the
battery and
associated circuitry
1
W
Temperature range -5 ÷ +40 °C
Dimensions (W*H*D) 445*578*111 mm
Weight 9Kg(without batteries)
Table 7 Technical features
