TERM. DESCRIPTION v(V) i(A)
MAIN BOARDS
+L1-
LEFT
(+)Loop 1-Positive signal, left side.
(-)Loop 1-Negative signal (return), left side
——
+L1-
RIGHT
(+)Loop 1-Positive signal, right side.
(-)Loop 1-Negative signal (return), right side
——
+L2-
LEFT
(+)Loop 2-Positive signal, left side.
(-)Loop 2-Negative signal (return), left side.
——
+L2-
RIGHT
(+)Loop 2-Positive signal, right side.
(-)Loop 2-Negative signal (return), right side.
——
[LC]
CONVENTIONAL LINE:
balanced line with 3900 ohm è control panel in standby
unbalanced line è Conventional Zone activated
line in short-circuit or open è fault on the Conventional Zone
——
[M] Ground 0 —
+485- SERIAL BUS. Terminals to connect the FC500REP and SLAVE control Panel — —
[M]
[24V]
24 V POWER Output for the FC500REP and SLAVE control Panel:
Positive pull-up to 27.6 V on [24V] terminal
Negative pull-down to0Von[M] terminal
27,6
0
0,5(1)
—
[AUX]
24 V AUXILIARY POWER SUPPLY:
negative present on terminal [M];
positive present on terminal [24A].
0
27,6 0,5(1)
[AUX-
RES]
24 V AUXILIARY POWER SUPPLY:
negative present on terminal [M];
positive present on terminal [24A].
0
27,6 0,5(1)
[NC]
[NO]
[C]
FIRE
FIRE ALARM OUTPUT - Non-Supervised:
standby è [C] connected to [NC] with [NO] open
;
in the event of ALARM è [C] connected to [NO] with [NC] open — —
[NC]
[NO]
[C]
FAULT
FAULT ALARM OUTPUT - Non-Supervised:
standby è [C] connected to [NC] with [NO] open
in the event of fault è [C] connected to [NO] with [NC] open — —
+BAT2- BATTERY CONTROL PANEL POWER SUPPLY 27,6
+BAT1- BATTERY CONTROL PANEL POWER SUPPLY 27,6
[OS1]...
[OS8]
Programmable Outputs(Open collector)- Silenceable-Bypassable (Disabled)-Supervised
(The polarity is not programmable)
27,6
[O9]...
[O16]
Programmable Outputs(Open collector)- Silenceable-Bypassable (Disabled)-NOT
Supervised
(The polarity is not programmable)
01
-NAC
FIRE+
Type C output (EN54-1) - Silenceable, Bypassable (Disabled), Supervised
Terminals for supervised devices activated by positive (24 V):
During ALARM status —— positive (27.6 V) on terminal [+]; negative on terminal [-].
27,6
[NAC1]
[NAC2]
[NAC3]
Programmable—Supervised—Silenceable—Bypassable (Disabled) ALARM Outputs:
Panel in Standby è negative on [+] terminal; positive 27.6V on [–] terminal
Panel in Alarm è positive 27.6V on [+] terminal; negative 0 V on [–] terminal —
(2)
[12V]
12 V AUXILIARY POWER SUPPLY:
on [12V] terminal è positive
on [M] terminal è negative
13,8
0
—
Table 8 Terminals description
