The Panda Generator
Seite/Page 48 - Kaptitel/Chapter A: The Panda Generator 19.8.14
Cooling water return flow
From here the cooling water heated up
flows into the radiator.
Fig. A.10: Cooling water return flow
De-aerating screw
The de-aerating screw at the water-cooled
pre-silencer is used at first time filling or
after repair work.
Fig. A.11: de-aerating screw
Return flow expansion tank
The breather pipe at the water-cooled
silencer leads to the external expansion
tank.
Fig. A.12: Return flow
