The Panda Generator
19.8.14 Kapitel/Chapter A: The Panda Generator - Seite/Page 47
Water-cooled exhaust manifold
The exhaust elbow union is cooled by the
water withdrawing from the cylinder head.
Fig. A.7: Water-cooled exhaust manifold
Cooling water pipe
Cooling water pipe from the water-cooled
exhaust elbow union to the water-cooled
pre-silencer.
Fig. A.8: Cooling water pipe
Water-cooled pre-silencer
Fig. A.9: Water-cooled pre-silencer
