I&J7000 Series Operating Manual
Section 4: Programming Example
Part # 561978B
Rev. H May 04
- Page 33 -
© 2003 I&J Fisnar Inc.
Instruction
Display Shows
9
Now jog the tip to the location of the third point
(3: Arc Point). When the location is correct, press
the ENTER key, then 5 to register the location as
an Arc point.
ADDR:5 PROG:10
EMPTY
10
Jog the tip to the location of the fourth point
(4: Line Passing). When the location is correct,
press the ENTER key, then 3 key to register the
location as a Line Passing point.
ADDR:6 PROG:10
EMPTY
11
Jog the tip to the location of the fifth point
(5: Line Passing). When the location is correct,
press the ENTER key, then 3 to register the
location as a Line Passing point.
ADDR:7 PROG:10
EMPTY
12
Jog the tip to the location of the sixth point
(6: Line Passing). When the location is correct,
press the ENTER key, then 3 to register the
location as a Line Passing point.
ADDR:8 PROG:10
EMPTY
13
Jog the tip to the location of the sixth point
(7: Line End). When the location is correct, press
the ENTER key, then 6 to register the location as a
Line End point.
ADDR:9 PROG:10
EMPTY
14
The line is now complete. The next step is to
register the dispense settings for the dots.
Press the SETUP key, then 3 to register the dot
dispensing time.
Point Dispense
Setup
--------------------
Dis. Time: sec
Tail Time: sec
unit: sec
15
Type 0.5 to register a dispensing time of 0.5
seconds, then press ENTER.
Type 0.1 to register a waiting time after dispensing
of 0.1 seconds, then press ENTER.
ADDR:10 PROG:10
EMPTY
16
Jog the tip to the location of first dispense point
(8: Dispense Point). When the location is correct,
press the ENTER key, then 1 to register the
location as a Dispense Point.
ADDR:11 PROG:10
EMPTY
17
Jog the tip to the location of second dispense point
(9: Dispense Point). When the location is correct,
press the ENTER key, then 1 to register the
location as a Dispense Point.
ADDR:12 PROG:10
EMPTY
18
Jog the tip to the location of third dispense point
(10: Dispense Point). When the location is
correct, press the ENTER key, then 1 to register
the location as a Dispense Point.
ADDR:13 PROG:10
EMPTY
19
The program is now complete.
Press ENTER, then 7 to register address 13 as the
END of the program.
ADDR:14 PROG:10
EMPTY
20
To run the program, press the RUN key..
