Thus, with the following schedule on the Schedule 1 connection:
And the following schedule on the Schedule 2 connection:
The following conguration le is obtained:
SCHEDULE_Params[0]=1|everyday|00:00:00|1440|1
SCHEDULE_Params[1]=2|monday|00:00:00|1440|1
SCHEDULE_Params[2]=3|rst|00:00:00|1440|1
SCHEDULE_Params[3]=4|middle|01:00:00|600|2
SCHEDULE_Params[4]=5|last|02:02:00|120|12
SCHEDULE2_Params[0]=1|everyday|00:00:00|1440|1
SCHEDULE2_Params[1]=2|everyday|00:00:00|3600|1
SCHEDULE2_Params[2]=3|everyday|00:00:00|86400|1
The index number is calculated automatically by the concentrator starting with 0. If this le is modied
manually, make sure there are no duplicate index numbers as this would result in the conguration being
