Fluidwell E018 User Manual

E119-P
FW_E119-P_M_v0301-02_EN Page 67
MODBUS-REGISTERS: TOTAL
[d] 1052
[h] 0x041C
41053 clear total
password
1 R/W uint16 000...999
Setting 000 disables the clear total password feature.
[d] 2146
[h] 0x0862
42147 contract hour 1 R/W uint16 0...23 Hour
[d] 2208
[h] 0x08A0
42209 current day total 4 R uint64 0.000 ... 99999999999
Representation: unit, decimals depending on variables 32,
33.
[d] 2216
[h] 0x08A8
42217 previous day
total
4 R uint64 0.000 ... 99999999999
Representation: unit, decimals depending on variables 32,
33.
MODBUS-REGISTERS: FLOWRATE
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 48
[h] 0x0030
40049 unit 1 R/W uint16 0=none
1=mL
2=L
3=m
3
4=US GAL
5=I GAL
6=CF
7=OilBBL
8=nL
9=nm
3
10=SCF
11=mg
12=g
13=kg
14=ton
15=lb
16=US
17=rev
18=P
[d] 49
[h] 0x0031
40050 time unit 1 R/W uint16 0=/sec 1=/min 2=/hour 3=/day
[d] 50
[h] 0x0032
40051 decimals 1 R/W uint16 0…3
[d] 51
[h] 0x0033
40052 K-factor 2 R/W uint32 1…9999999
Representation: 0.000010…9999999 depending on variable
54: decimals K-factor
[d] 54
[h] 0x0036
40055 K-factor
decimals
1 R/W uint16 0…6
[d] 55
[h] 0x0037
40056 number of
pulses
1 R/W uint16 1…255
[d] 56
[h] 0x0038
40057 cut-off time 1 R/W uint16 1…9999
Representation: 0.0001…9.999sec
[d] 62
[h] 0x003E
40063 filter 1 R/W uint16 1…99
MODBUS-REGISTERS: DISPLAY
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 64
[h] 0x040
40065 display function 1 R/W uint16 0=total 1=flowrate 2=acc.total
[d] 2147
[h] 0x863
42148 day totals 1 R/W uint16 0=hidden 1=operate 2=off
[d] 80
[h] 0x050
40081 LCD update
time
1 R/W uint16 0=fast
1=1sec
2=3sec
3=15sec
4=30sec
5=off
[d] 67
[h] 0x043
40068 backlight
brightness
1 R/W uint16 0=off
1=20%
2=40%
3=60%
4=80%
5=100%
[d] 58
[h] 0x03A
40059 bar graph
enable
1 R/W uint16 0=disable 1=enable
[d] 59
[h] 0x03B
40060 bar graph range 2 R/W uint32 0…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
MODBUS-REGISTERS: FLOWMETER
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 96
[h] 0x060
40097 flowmeter signal 1 R/W uint16 0=NPN
1=NPN LP
2=reed
3=reed LP
4=PNP
5=PNP LP
6=Namur
7=coil hi
8=coil lo
9=act 8.2V
10=act 24V
[d] 1051
[h] 0x41B
41052 K-factor unit
type
1 R/W uint16 0=hand 1=volumetric 2=mass
