E119-P
Page 68 FW_E119-P_M_v0301-02_EN
MODBUS-REGISTERS: FLOWMETER
[d] 1050
[h] 0x41A
41051 K-factor unit 1 R/W uint16 0=none
1=L
2=m
3
3=US GAL
4=I GAL
5=CF
6=OilBBL
7=kg
8=ton
9=LB
10=US ton
[d] 1046
[h] 0x416
41047 K-factor 2 R/W uint32 1…9999999
Representation: 0.000010…9999999 depending on variable
54: decimals K-factor
[d] 1049
[h] 0x419
41050 K-factor
decimals
1 R/W uint16 0…6
MODBUS-REGISTERS: LINEARIZATION
The linearization table is an INDEXED variable. Reading and writing the entries of the linearization table is done by first selecting the
entry through the index. Valid values for the index are 0…14, which correspond with the linearization table entries 1 through 15.
Indexes outside this range will result in an error being sent back. (See the communication-section of this appendix for setting the index
and its extended functionality through variable 150 and 149).
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 1024
[h] 0x400
41025 linearization
table entry
3
INDEXED
variable
R/W struct
2x
uint24
The three registers represent a structure containing 2
variables of each 3 bytes. The three least significant bytes
(PDU address 1024 and LSB of PDU address 1025) contain
the frequency part, the three most significant bytes (MSB of
PDU address 1025 and PDU address 1026) contain the
Mfactor part.
Valid range for the frequency is 0.000 to 9999Hz. Decimal
point dependent on variable 1039. A value of 0 for frequency
means that entry is disabled.
Valid range for the M-factor 0.000000 to 9.999999.
[d] 1038
[h] 0x40E
41039 linearization on/
off
1 R/W uint16 0=disable 1=enable
[d] 1039
[h] 0x40F
41040 decimals 1 R/W uint16 0…3
This variable selects the number of decimals used for the
frequencies entered in the linearization table.
MODBUS-REGISTERS: REMOTE CONTROL INPUTS
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 217
[h] 0x0D9
40218 Remote 1 1 R/W uint16 0=off
1=clear total
2=end
delivery
3=print
totalizer
4=reprint
[d] 111
[h] 0x06F
40112 Remote 2 1 R/W uint16 0=off
1=clear total
2=end
delivery
3=print
totalizer
4=reprint
MODBUS-REGISTERS: ANALOG OUTPUT
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 112
[h] 0x070
40113 analog output 1 R/W uint16 0=disable 1=enable
[d] 113
[h] 0x071
40114 minimum rate 2 R/W uint32 0.001…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 116
[h] 0x074
40117 maximum rate 2 R/W uint32 0.001…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 119
[h] 0x077
40120 cut-off
percentage
1 R/W uint16 0…99
Representation: 0.0…9.9%
[d] 120
[h] 0x078
40121 tune minimum
output
1 R/W uint16 0…9999
[d] 122
[h] 0x07A
40123 tune maximum
output
1 R/W uint16 0…9999
[d] 127
[h] 0x07F
40128 filter 1 R/W uint16 0…99
