Fluidwell E018 User Manual

E119-P
FW_E119-P_M_v0301-02_EN Page 69
MODBUS-REGISTERS: PULSE OUTPUT
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 141
[h] 0x08D
40142 pulse mode 1 R/W uint16 0=disable 1=scaled 2=retrans
[d] 128
[h] 0x080
40129 pulse time width 1 R/W uint16 0…9999
Representation: 0.001…9.999sec
[d] 130
[h] 0x082
40131 pulse per X
quantity
2 R/W uint32 1…9999999
Representation: 0.000001…9999999 depending on variable
133
[d] 133
[h] 0x085
40134 pulse quantity
decimals
1 R/W uint16 0…3
MODBUS-REGISTERS: COMMUNICATION
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 146
[h] 0x092
40147 communication
mode
1 R/W uint16 0=off 1=RTU 2=ASCII 3=printer
[d] 144
[h] 0x090
40145 speed
(baudrate)
1 R/W uint16 0=1200
1=2400
2=4800
3=9600
4=9600HP
5=19200
6=38400
7=57600
[d] 1271
[h] 0x4F7
41272 data bits 1 R/W uint16 0=7bit 1=8bit
[d] 1272
[h] 0x4F8
41273 parity 1 R/W uint16 0=none 1=even 2=odd
[d] 145
[h] 0x091
40146 modbus
address
1 R/W uint16 1…247
[d] 147
[h] 0x093
40148 transmit delay 1 R/W uint16 0…255ms
delay between receiving a (valid) modbus command and
sending the response
[d] 150
[h] 0x096
40151 index 1 R/W uint16 0…255
used for indexed values
[d] 149
[h] 0x095
40150 index use 1 R/W uint16 0=static 1=auto
increment
2=auto
decrement
[d] 25
[h] 0x019
40026 reboot 1 R/W uint16 Returns 0 on read
Write 0xA50F for unit restart
Write 0x5AF0 for factory settings
[d] 1606
[h] 0x646
41607 line delay 1 R/W uint16 0…255
Representation: 0.00…2.55 sec
[d] 142
[h] 0x08E
40143 line termination 1 R/W uint16 0=CR/LF 1=CR 2=LF
[d] 151
[h] 0x097
40152 empty lines
start
1 R/W uint16 0…9
[d] 152
[h] 0x098
40153 empty lines end 1 R/W uint16 0…9
[d] 153
[h] 0x099
40154 form feed 1 R/W uint16 0=disable 1=enable
[d] 143
[h] 0x08F
40144 date format 1 R/W uint16 0=Y.M.D 1=D.M.Y 2=M.D.Y
MODBUS-REGISTERS: TICKET
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO. OF
REG’S
R/W TYPE VALUES / REPRESENTATION / REMARKS
[d] 1776
[h] 0x6F0
41777 header 1 1 R/W char[] Array of 16 printable characters (ASCII-code 32…127).
[d] 2048
[h] 0x800
42049 header 2 1 R/W char[] Array of 16 printable characters (ASCII-code 32…127).
[d] 2064
[h] 0x810
42065 header 3 1 R/W char[] Array of 16 printable characters (ASCII-code 32…127).
[d] 2080
[h] 0x820
42081 header 4 1 R/W char[] Array of 16 printable characters (ASCII-code 32…127).
