Table 49. Replaceable Parts (cont.)
Reference
Designator
Description Fluke PN Qty
26 6270-2030,RETAINER, SCREEN, CPS 4542532 1
27
FILTER SCREEN,SS CYLINDER,19MM ID,25.4MM L,165 X 800
WIRE FILTER MESH
4613942 1
28
O-RING,20MM ID X 2MM
W,VITON/FLUOROELASTOMER,A75,BLACK
4581522 1
29 6270-2029,RETAINER, FILTER, CPS 4542526 1
30
O-RING,6MM ID X 3MM
W,VITON/FLUOROELASTOMER,A70,BLACK
4581546 1
31 FILTER,COALESCING,25MM ID,51MM L,70K GRADE,DISPOSABLE 4578779 1
32 6270-2025,HOUSING, LOWER, CPS 4542483 1
33
O-RING,35MM ID X 2MM
W,VITON/FLUOROELASTOMER,A75,BLACK
4581568 1
34 HC20 Mounting Post Kit 4755373 1
35
O-RING,3MM ID X 1.5MM
W,VITON/FLUOROELASTOMER,A75,BLACK
4581554 1
36 6270-2023,POST, MOUNTING, P3000 4542465 1
37
SCREW,M4X0.7,12MM,FLAT,PHILLIPS,STAINLESS
STEEL,PASSIVATED,ROHS COMPL.
2184957 6
38 54-703-10,O-RING VITON 1/4 X 1/16 X SEC 3865195 3
39 103339-Z,FOOT,BLK NITRILE,DIA 13.6 3154424 4
40 6270-4419,CABLE, LED, CPS 4686352 1
41 102118,BHD, SS, QC X 4T 3135553 1
42 102630-Z,WASHER,LOCK,SPLIT,STAINLESS,#7/16 3153906 1
43 2271A-CPS,HOSE ASSEMBLY, CPS 4724451 1
44
CPS to Chassis Cable assembly, includes parts 4743487, 142554,
4579040, 4744744, 4744732, 1304633, 4751318
4823574 1
45 SOFT CASE,POLYESTER,BLK/YEL,C35 2670161 1
46 103047,BOTTLE,125ML,WIDEMTH HDPE 3139442 1
47 FOAM,CPS W/LED, SET - shipping 4744575 1
48 BOX,CPS,RSC PLAIN 48DW - shipping 4744594 1
49 Assembly, Dual Solenoid Valves, 4 pin connector, W/O LED 4582366 1
50 CPS to Chassis Cable Assembly, 4 pin connector, W/O LED 4578818 1
