Fluke ScopeMeter 190 II Series Service Manual

Performance Verification
Scope Input A, B, C, D Tests 4
4-13
Table 4-3. Volts DC Measurement Verification Points
Range 5502A Output V dc 2 Channel Input Reading 4 Channel Input Reading
2 mV/div
+6.0 mV +4.9 to +7.1 +4.8 to +7.2
-6.0 mV -7.1 to -4.9 -7.2 to -4.8
5 mV/div
+15.0 mV +14.2 to +15.8 +13.9 to +16.1
-15.0 mV -15.8 to -14.2 -16.1 to -13.9
10 mV/div
+30.0 mV +28.9 to +31.1 +28.5 to +31.5
-30.0 mV -31.1 to -28.9 -31.5 to –28.5
20 mV/div
+60.0 mV +58.5 to +61.5 57.6 to 62.4
-60.0 mV -61.5 to -58.5 -62.4 to -57.6
50 mV/div
+150 mV +142 to +158 +139 to +161
-150 mV -158 to -142 -161 to -139
100 mV/div
+300 mV +289 to +311 +285 to +315
-300 mV -311 to -289 -315 to -285
200 mV/div
+600 mV +585 to +615 +576 to +624
-600 mV -615 to -585 -624 to -576
500 mV/div
+1.50 V +1.42 to +1.58 +1.39 to +1.61
-1.50 V -1.58 to -1.42 -1.61 to -1.39
1 V/div
+3.00 V +2.89 to +3.11 +2.85 to +3.15
-3.00 V -3.11 to -2.89 -3.15 to -2.85
2 V/div
+6.00 V +5.85 to +6.15 +5.76 to +6.24
-6.00 V -6.15 to -5.85 -6.24 to -5.76
5 V/div
+15.0 V +14.2 to +15.8 +13.9 to +16.1
-15.0 V -15.8 to -14.2 -16.1 to -13.9
10 V/div
+30.0 V +28.9 to +31.1 +28.5 to +31.5
-30.0 V -31.1 to -28.9 -31.5 to –28.5
20 V/div
+60.0 V +58.5 to +61.5 57.6 to 62.4
-60.0 V -61.5 to -58.5 -62.4 to -57.6
50 V/div
+150 V +142 to +158 +139 to +161
-150 V -158 to -142 -161 to -139
100 V/div
+300 V +289 to +311 +285 to +315
-300 V -311 to -289 -315 to -285
