TCP/IP Setting
Open the [MFR-TALM Web-based Control: Port Settings page] and perform port settings
under TCP/IP Port.
Port
Menu
[Port Settings] - [TCP/IP Port]
Access
Method
IP Address
Port
Function
Web-based Control
[TALM Settings]
Client
(MV
IP address)
(MV TCP/IP
port number)
TSL UMD protocol
V5.0 Tally out
Encode
DLE
Screen No.
Unicode
ON
(Set the same as in
MV)
Data transmission settings between HVS-2000 and MFR-TALM
<HVS-2000-side>
 To receive name data from the router, set LINK in the ROUTER NAME menu to MFR.
 Perform the TALLY COLOR and TALLY UNIT settings so that the MFR-TALM unit can
receive switcher tally data.
<MFR-TALM-side>
 Open the [MFR-TALM Web-based Control: HVS-TAL Protocol Reception page] and
perform the same tally settings as those in HVS-2000.
The tally settings in the MFR system must be entered in the [MFR-TALM Web-based
Control: Tally System Settings page]. When using MFR-TALM for tally control, the [Main
unit Web-based Control: Tally System Settings page] and its subpages are all disabled.
Refer to your mulitviewer's user guide for the details on how to handle tally data on the
multiviewer.
