FOR-A MFR Series User Manual

49
MainBoard Status
Displays information on the main board as follows.
FPGA Version
Displays the FPGA version information.
xx V
Displays the voltage level. (The power voltage
level varies depending on the unit)
Temperature *1
Displays the temperature.
Crosspoint Error *4
Indicates whether or not there is a Crosspoint
Error.
FAN Status *2
Indicates the Matrix fan status.
SRCPU Board Status
FPGA Version
Displays the FPGA version.
xx V
Displays voltage status.
(Varies depending on the main unit.)
Power Supply Status
Displays information on the power unit as follows.
Active
Displays the power unit status.
AC/DC/ Temperature/
Internal FAN Alarm *4
Indicates the power voltage (AC and DC),
temperature, and power unit fan alarm status.
Shutdown
Indicates high-temperature protection alarm
status.
SDI Status *3
Displays whether or not there is SDI signal and reclocking status.
(Available when an MFR-1616/1616R/3216/3232 main unit is used)
Reclock Status *3
Displays reclock status of SDI signals.
*1 Available when an MFR-5000/8000 main unit is used.
*2 Available when an MFR-8000 main unit is used.
*3 Available when an MFR-1616/1616R/3216/3216RPS/3232/3232RPS main unit is used.
*4 Available when an MFR-5000/8000/3000 main unit is used.
*5 Displayed as "MFR-30CPU" in MFR-3000 main unit.
*6 Displayed as "MFR-3000CPU" in MFR-3000 main unit.
