CHAPTER 1: MACHINE OVERVIEW
In this chapter:
1.1 Intended use 18
1.2 Technical data 19
1.3 Exterior components 20
1.4 Engine compartment overview 22
1.5 Chipping chamber overview 24
1.6 Autointelligence system 25
1.7 Feed roller controls 26
1.8 Control panel 27
1.9 Emergency stop buttons 28
1.10 Control Screen 29
1.10.1 Button Functions 30
1.10.2 Navigation 31
1.10.3 Home screen 32
1.10.4 Sensors and DPF 33
1.10.5 Machine Information 34
1.10.6 Active Engine Codes (DM1) 35
1.10.7 Historic engine codes (DM2) 36
1.10.8 Settings 37
1.10.9 Alarm Splash Screen 38
1.11 Ignition switch 39
1.12 Manufacturer’s statutory plate 40
1.13 Vehicle identification number (VIN) plate 41
