4.5 FEED ROLLER SPEED ADJUSTMENT
The feed roller speed can be adjusted to suit the material being chipped, refer to Figure
39.
1. Turn dial to align number with paint spot.
2. Set the feed roller speed so that the No-Stress operates as little as possible, this will
give the highest throughput.
3. When feeding Leylandii or leafy material, set the feed roller speed to 4.5.
4. Control valve speed adjustment.
Position indicated by paint spot. (1, Figure 39):
l
0 = Minimum
l
10 = Maximum
Figure 39 - Feed roller speed adjustment
Chapter 4: Operation
Redwood Global Ltd - ST6D42
Operator and Maintenance Manual
73 12-00-004 v2.1
