FORST ST6D42 - Emergency Stop Buttons

Redwood Global Ltd - ST6D42
Operator and Maintenance Manual
Chapter 1: Machine Overview
1.9 EMERGENCY STOP BUTTONS
WARNING
Pushing an emergency stop button does not stop the engine.
There is one emergency stop button located on the top of the hopper.
Push the emergency stop to stop the feed rollers instantly.
1 Emergency stop button
Figure 8 - Emergency stop button
NOTICE
Pull the emergency stop button up to reset.
12-00-004 v2.1 28
