MicroLog Plus Chapter 2
109
2.3.3. Multiple graphs View
Click Multiple graphs
on the main toolbar to switch to
Multiple graphs view.
In Multiple graphs view, the data for each MicroLog is displayed
in a separate window in graphs. The graphs display the data sets
plotted versus time. In order to keep the graph clear and simple,
only two Y-axes can be shown on the graph simultaneously. If
there are three curves in the graph, one of the Y-axes will be
hidden. To make this axis visible, select the corresponding plot
with the cursor.
You can identify the Y-axis by its color, which matches the plot
color.
