Fourier MicroLog - Connect Microlog to an External Sensor

MicroLog Chapter 1
29
Note: You can also connect to the PC via the Cradle (see page
162).
2. Connect MicroLog to an external sensor
Use the same PC connection socket to connect to an external
sensor (see Figure 1).
Note that the socket has three pins, with one further away from the
other two (Figure 1). Take care to plug the cable in correctly.
Note: You can also connect the external sensor to the Cradle
(see page 162).
