Chapter 3 The Cradle
166
4. Replace the front cover, turn the cradle over
and refasten the four screws at the back of the
cradle.
3.4. Screw Terminals
The cradle is equipped with eight screw terminals for permanent
connections to the cradle. These terminals include:
Connection to external sensor: Identical to the cradle’s external
sensor socket.
Contact sensor (DT175 only): This cradle sensor (in addition to
the usual external contact sensor) monitors Reed Relay contacts
and switch status (open/closed) to identify the correlation between
phenomena such as temperature change and door status. This
