External sensors Chapter 5
187
OV protection: +30V
6.5. Current Sensor
This MicroLog external sensor can sample any device or
transmitter producing a linear current of 0-20mA. The 0-20mA can
be converted to the correct measured units using the MicroLab
software’s Calibration option.
Specifications:
Range: 0-20mA
Resolution: ±0.1mA
Accuracy: ±3 before calibration
Calibration: Two point calibration
OC protection: 55mA
