External Magnet Antenna Chapter 5
179
5.3. Preparing the Cradle to work
with the external antenna
The Cradle is equipped with an internal jumper that connects the
transmitter either to the built in wipe antenna or to the external
magnet antenna.
To change the jumper position:
1. Unfasten the four screws at the back of the
Cradle
2. Carefully rotate the Cradle
3. Remove the front cover
4. Place the jumper in the desired position
