Chapter 5 External sensors
186
Screw terminals for PT100 connection
6.4. Voltage Sensor
This is a general sensor that will measure any device or transmitter
that produces a linear analog output of 0-10V. The voltage can
easily be converted to the correct measured units with the help of
the MicroLab software.
Specifications:
Range: 0-10V
Resolution: 0.05V
Accuracy: ±3% before calibration
Input Impedance: 3MΩ
Calibration: Two point calibration
