External Magnet Antenna Chapter 5
177
1. Open the receiver case, by releasing the four screws on the
receiver back
2. Remove the wipe antenna from the screw terminal
3. Connect the antenna hot wire to the right terminal of J1
(wipe antenna location)
4. Connect the antenna shield wire to the left terminal
5. Close the receiver using its four screws
5.2. Connecting the antenna to the
Cradle
All Cradles produced after March 2003 have an SMA connector on
their right side.
