Chapter 2 MicroLog Plus
94
The Offline Graph menu contains all the commands needed to
format and edit the graph.
The Cradle Map menu contains all the commands needed to setup
and edit the map.
The Multiple Graphs menu contains all the commands needed to
view and edit the graphs.
The most common tasks and commands are available as buttons on
the Main toolbar (upper toolbar), the Graph toolbar (lower
toolbar) and on the Cradle map toolbar (lower toolbar).
2.1.1. MicroLab Plus Default Window Layout
In Meters view (the default view), the data for each MicroLog is
displayed in a separate window in a meter. There are six MicroLog
windows in each display. The picture below represents an
individual MicroLog display.
