MicroLog Plus Chapter 2
123
2.4.4. Graph display
1. Graph
The graph displays the data sets plotted vs. time.
In order to keep the graph clear and simple, only two Y-axes can
be shown on the graph simultaneously. If there are three curves in
the graph, one of the Y-axes will be hidden. To make this axis
visible, select the corresponding plot with the cursor.
You can identify the Y-axis by its color, which matches the plot
color.
2. The Cursor
Use the cursor to view individual data recording values, or to
reveal a hidden Y-axis.
