Chapter 3 The Cradle
162
3.2. Operating the Cradle
1. Place the MicroLog in
the cradle so that its rear
connection socket fits into
the plug on the cradle.
Figure 6: MicroLog and Cradle
2a. RS232 serial
communication socket
3. External
sensor input
Trs
button
2b. USB socket
4. DC power
input
Led
indicator
