Chapter 2 MicroLog Plus
144
3. In the Based On drop list, select an external sensor that
matches your sensor’s output
4. Type the sensor’s name in the Sensor Name edit box.
5. Type the sensor’s unit in the Sensor Unit edit box.
6. In the Calibration Values section, enter two values of
your sensor that correspond to the base sensor values.
For example, see the definition for a 0 – 100mbar
pressure sensor whose output is 0 – 20mA:
