REGISTER SUMMARY MC68332
D-6 USER’S MANUAL
SUPV — Supervisor/Unrestricted Data Space
The SUPV bit places the SIM global registers in either supervisor or user data space.
0 = Registers with access controlled by the SUPV bit are accessible from either the
user or supervisor privilege level.
1 = Registers with access controlled by the SUPV bit are restricted to supervisor
access only.
MM — Module Mapping
0 = Internal modules are addressed from $7FF000 – $7FFFFF.
1 = Internal modules are addressed from $FFF000 – $FFFFFF.
IARB[3:0] — Interrupt Arbitration Field
Determines SIM interrupt arbitration priority. The reset value is $F (highest priority), to
prevent SIM interrupts from being discarded during initialization.
D.2.2 SIMTR — System Integration Test Register $YFFA02
SIMTR is used for factory test only.
D.2.3 SYNCR — Clock Synthesizer Control Register $YFFA04
SYNCR determines system clock operating frequency and mode of operation. Clock
frequency is determined by SYNCR bit settings as follows:
W — Frequency Control (VCO)
0 = Base VCO frequency
1 = VCO frequency multiplied by four
X — Frequency Control Bit (Prescale)
0 = VCO frequency divided by four (base system clock frequency)
1 = VCO frequency divided by two (system clock frequency doubles)
Y[5:0] — Frequency Control (Counter)
The Y field is the initial value for the modulus 64 down counter in the synthesizer feed-
back loop. Values range from 0 to 63.
EDIV — ECLK Divide Rate
0 = ECLK is system clock divided by 8
1 = ECLK is system clock divided by 16
SLIMP — Limp Mode
0 = External crystal is VCO reference
1 = Loss of crystal reference
SLOCK — Synthesizer Lock
0 = VCO is enabled, but has not locked.
1 = VCO has locked on the desired frequency or system clock is external.
15 14 13 8 7 6 5 4 3 2 1 0
W X Y EDIV 0 0 SLIMP SLOCK RSTEN STSIM STEXT
RESET:
0 0 1 1 1 1 1 1 0 0 0 U U 0 0 0
