MC68332 SYSTEM INTEGRATION MODULE
USER’S MANUAL 4-13
010010 80 160 320 640
010011 84 168 336 672
010100 88 176 352 704
010101 92 184 368 736
010110 96 192 384 768
010111 100 200 400 800
011000 104 208 416 832
011001 108 216 432 864
011010 112 224 448 896
011011 116 232 464 928
011100 120 240 480 960
011101 124 248 496 992
011110 128 256 512 1024
100000 132 264 528 1056
100001 136 272 544 1088
100010 140 280 560 1120
100011 144 288 576 1152
100100 148 296 592 1184
100101 152 304 608 1216
100110 156 312 624 1248
100111 160 320 640 1280
101000 164 328 656 1312
101001 168 336 672 1344
101010 172 344 688 1376
101011 176 352 704 1408
101100 180 360 720 1440
101101 184 368 736 1472
101110 188 376 752 1504
101111 192 384 768 1536
110000 196 392 784 1568
110001 200 400 800 1600
110010 204 408 816 1632
110011 208 416 832 1664
110100 212 424 848 1696
110101 216 432 864 1728
110110 220 440 880 1760
110111 224 448 896 1792
111000 228 456 912 1824
111001 232 464 928 1856
111010 236 472 944 1888
111011 240 480 960 1920
111100 244 488 976 1952
111101 248 496 992 1984
111110 252 504 1008 2016
111111 256 512 1024 2048
Table 4-7 Clock Control Multipliers (Continued)
To obtain clock frequency in kilohertz, find counter modulus in the left column, then multiply reference frequency by value
in appropriate prescaler cell.
Modulus Prescalers
Y [W:X] = 00 [W:X] = 01 [W:X] = 10 [W:X] = 11
