Fronius Primo 3.0-1 Service Manual

152
Function tests
Function Functions that the testing personnel consider to be relevant must be tested for correct op-
eration.
Energising and feeding-in of the inverter.
Grid on/off devic-
es
Evidence of proper operation must be provided by measurement or visual inspection.
AC and DC main switch check (perform when under no or minimal load, but not in standby
mode)
- Switch off DC main switch -> inverter must switch to error and stop feeding in energy
- Switch off AC main switch -> inverter switches off and display goes out
- Switch on AC main switch and DC main switch
- Perform a fan test - see operating instructions
Indicators and
control elements
- Check display for correct function
- Check that controls work in line with the operating instructions

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
