Fronius Primo 3.0-1 Service Manual

84
Troubleshooting
guide
Used to systematically locate and rectify errors.
Replacing com-
ponents
The "Replacing components" chapter describes how to replace components that
- have no instructions of their own for replacement and
- require detailed replacement instructions
Safety inspection This section outlines the safety inspection for the device described in this service manual.
Please be aware of the requirements and standards relevant to your country, as the meas-
ured values or steps taken during the tests may vary.
Even if there are no relevant requirements and standards in your country, Fronius recom-
mends that this inspection should still be carried out.
The safety inspection must only be carried out on a fully assembled device.
Appendix The Appendix contains the complete spare parts list and circuit diagram for the device. The
circuit diagram is also supplied with the device.

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
