Fronius Primo 3.0-1 Service Manual

106
Error flowchart
General The error search tree is used to systematically locate and rectify errors.
Before starting any troubleshooting activities, read the "Function overview" section in order
to understand the layout of the device and how it works.
Essential system data:
- Inverter type
- Serial number of the installed inverter
- Service code shown on the display (State PS menu)
- Name of PV system (name of system operator)
- System operating period
- Location of system
- Number of inverters installed in system (type, serial number)
- DC and AC voltage
Permanent faults
tŚĞŶĚŽĞƐƚŚĞĨĂƵůƚŽĐĐƵƌ
/ŶǀĞƌƚĞƌĨĂƵůƚƵŶůŝŬĞůLJ
;ĐŚĞĐŬŐƌŝĚƐŽůĂƌŵŽĚƵůĞƐͿͲ
ĨŽƌĚĞƚĂŝůƐƐĞĞůŝƐƚŽĨ&ƌŽŶŝƵƐƐĞƌǀŝĐĞ
/ŶǀĞƌƚĞƌĨĂƵůƚůŝŬĞůLJ
;WďŽĂƌĚŝŶǀĞƌƚĞƌŵƵƐƚďĞƌĞƉĂŝƌĞĚͿ
ͲĨŽƌĚĞƚĂŝůƐƐĞĞůŝƐƚŽĨ&ƌŽŶŝƵƐ
ƐĞƌǀŝĐĞĐŽĚĞƐ
ƌĞŽƚŚĞƌĚĞǀŝĐĞƐ
ĂůƐŽĚŝƐƉůĂLJŝŶŐĂĨĂƵůƚ
z^ EK
ĐŽĚĞƐ

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
