9
DE
Werkzeug und Messgeräte
Allgemeines „Werkzeug und Messgeräte“ bietet eine Übersicht und Beschreibung aller Hilfsmittel, die
für ein fachgerechtes Service des Gerätes erforderlich sind. Dazu zählen folgende Hilfs-
mittel:
- Erforderliches Werkzeug
- Mess- und Prüfmittel
- Hilfsmaterialien
Erforderliche
Werkzeuge
- Torx Schraubendreher TX 20
- Torx Schraubendreher TX 25
- Schlitz-Schraubendreher 3 mm
- Steckschlüssel
- Steckschlüssel-Einsatz SW 7 mm
- Steckschlüssel-Einsatz SW 36 mm
- Steckschlüssel-Einsatz SW 41 mm
- Gabelschlüssel SW 7 mm
- Gabelschlüssel SW 36 mm
- Gabelschlüssel SW 41 mm
- Seitenschneider
- Spitzzange
- Drehmoment-Schrauber mit Bit-Satz 1 - 6 Nm
- Drehmoment-Ratsche 1 - 10 Nm
Mess- und Prüf-
mittel
- Digitales Multimeter
- Equipment für die sicherheitstechnische Überprüfung
Hilfsmaterialien - Reinigungsmaterial (Spray, Papier)
- Kabelbinder 102 (42,0407,0099)
- Wärmeleitfolie TPC (42,0300,3054)
- Schraube mit Dichtscheibe PT 5x25 (42,0401,4231)
- Wärmeleit-Pad (42,0300,3138)
