Fronius Primo 3.0-1 Service Manual

92
The GPIS SoftStart function is activated according to the country setup:
after cutting out due to an AC error, the output power of the inverter is continuously in-
creased by 10% every minute in line with the VDE-AR-N 4105 guideline.
Code Description Behaviour Remedy
102 Grid voltage exceeding per-
mitted limit
1. Grid voltage fault 1. Check grid voltage
2. Incorrect values in Service
menu / incorrect setup
2. Check values in Service
menu / check setup
3. Poor contact: wall bracket <-
-> filter PC board
3. Replace filter PC board
103 Grid voltage under permit-
ted limit
1. Grid voltage fault 1. Check grid voltage
2. Incorrect AC wiring 2. Check AC wiring
3. Incorrect values in Service
menu / incorrect setup
3. Check values in Service
menu / check setup
4. Poor contact: wall bracket <-
-> filter PC board
4. Check fixing screws in the
DATCOM area
5. Measurement fault on filter
PC board
5. Replace filter PC board
105 Grid frequency exceeding
permitted limit
1. Grid frequency fault 1. Check grid frequency
2. Incorrect values in Service
menu / incorrect setup
2. Check values in Service
menu / check setup
3. Recombination limit reached 3. Normal legal requirement,
no fault (50.05 Hz)
4. Ripple control signals 4. Report to Fronius Technical
Support specialists
5. Measurement fault on filter
PC board
5. Replace filter PC board
106 Grid frequency under per-
mitted limit
1. Grid frequency fault 1. Check grid frequency
2. Incorrect values in Service
menu / incorrect setup
2. Check values in Service
menu / check setup
3. Ripple control signals 3. Report to Fronius Technical
Support specialists
4. Measurement fault on filter
PC board
4. Replace filter PC board
107 Synchronisation with public
grid supplier not possible
1. Incorrect values in Service
menu / incorrect setup
1. Check values in Service
menu / check setup
2. Poor contact between power
stage set and AC
2. Check AC connection
screws
3. Poor AC connection 3. Check grid connection
4. Measurement fault on filter
PC board
4. Replace filter PC board

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
