Fronius TPS 4000 Operating Instructions

Controls and
connections,
versions 2 and 3
(1)(2)
Front view. TPS 3200 600/575 - 460 V, TPS
5000 600/575 - 460 V auto-transformers
(5)
(6)
(4) (3)
Rear view. TPS 3200 600/575 - 460 V, TPS 5000
600/575 - 460 V auto-transformers
(1) Main switch
central switch for turning all welding system components on and off
(2) 230 V fan fuse
T400mA/500V
(3) Power source connection cable „OUTPUT 460 50/60 Hz“
for supplying the power source with the transformed voltage.
(4) Mains cable „INPUT 600/575 V 50/60 Hz“
for supplying the auto-transformer with the mains voltage
(5) Blanking cover
(6) Blanking cover
