Fronius TPS 4000 Operating Instructions

TPS/MW 5000 -
480-455 V auto-
transformer
Mains voltage 1 (+/- 10 %) 3 x 480 V / 50 / 60 Hz
Output voltage (+/- 10 %) 3 x 455 V
Mains fuse protection (slow-blow) 32 A (480V)
Maximum apparent power 27.6 kVA
Effective apparent power 20.7 kVA
Cos phi 0.9
Maximum primary current for
Mains voltage 1 (480V) 33 A
Effective primary current for
Mains voltage 1 (480V) 25 A
Secondary current at
10 min / 40 °C 40 % d.c.*
10 min / 40 °C 100 % d.c.*
35 A
26 A
Protection IP 23
Type of cooling AN (Air, Natural convection)
Insulation class B
Dimensions l x w x h 625 x 290 x 230 mm
25.59 x 11.42 x 9.06 in.
Weight 23 kg
50.71 lbs
Marks of conformity CSA
* duty cycle
58
