Technical data
Safety
NOTE!
Incorrectly rated mains plugs, mains leads or fuses can result in serious dama-
ge. If the power source is designed for a special voltage, the technical data on
the rating plate apply. Rate the mains plug, mains lead and their fuse protection
accordingly.
TPS 2700
600/575-460 V
autotransformer
Mains voltage 1 (+/- 10 %) 3 x 600 V / 50 / 60 Hz
Mains voltage 2 (+/- 10 %) 3 x 575 V / 50 / 60 Hz
Output voltage (+/- 10 %) 3 x 460 V / 440 V
Mains fuse protection (slow-blow) 13 A (600V)
13 A (575 V)
Maximum apparent power 10.4 kVA
Effective apparent power 5.5 kVA
Cos phi 0.9
Maximum primary current for
Mains voltage 1 (600V)
Mains voltage 2 (575 V)
10 A
10.5 A
Effective primary current for
Mains voltage 1 (600V)
Mains voltage 2 (575 V)
5.3 A
5.6 A
Secondary current at
10 min / 40 °C 40 % d.c.*
10 min / 40 °C 100 % d.c.*
13 A
7 A
Protection IP 23
Type of cooling AN (Air, Natural convection)
Insulation class B
Dimensions l x w x h 625 x 290 x 230 mm
25.59 x 11.42 x 9.06 in.
Weight 27 kg
59.52 lbs
Marks of conformity CSA
* duty cycle
