Other signals used for TIG welding
Cold wire disable The “KD disable” signal facilitates the changeover from internal to external control of the
cold-wire feed unit:
- “KD disable“ not set = “KD enable“:
Internal control of the cold-wire feed unit via the power source
- “KD disable“ set:
External control of the cold-wire feed unit via the robot interface
External or internal control of the cold-wire feed unit affects the following functions:
- Wire feed
- Wire retract
External box If option 4,101,039 “I-set TIG interference suppression external box“ is installed on the in-
terface (external box), a cold-wire feeder must not be connected to the LocalNet sockets
of the interface.
Instead, a cold-wire feeder must be connected directly to the TIG power source via a pas-
sive distributor, to ensure trouble-free operation.
